JVS-D6004 DVR
The Jovision JVS-D6000 series Network DVR is low-end stable product
due to its full metallic case, H.264 coding standard, standalone linux
operation system and high-speed CPU. JVS-D6000 can support video capture
and compression, network transmission, remote control, PTZ control, motion
detection and mobile remote viewing. In addition, JVS-D6000 can work
individually and work within a security network, so JVS-D6000 can keep the
functions of DVR and DVS. JVS-D6000 can be used in a large scope, such as
schools, factories, supermarket, bank, telecom, traffic, living district,
warehouse and so on.
Functions:
Featured Functions:
1. Support Mobile Phone Viewing
2. Support Snapshot and Snapshot Management
3. Support System log and Search
4. Set the rights of local users and network users
5. Enable temporary user if forget login password
6. Support Audio talk between host-end and client-end
7. Support software update (USB Device, FTP and Jovision Website)
Previewing:
1. Support PAL/NTSC
2. Previewing Resolution: D1
3. Adjust video parameters of every channel individually
4. Support up to 4 privacy Areas in each channel
5. Support single channel or 4 channels previewing
Compression:
1. Use H.264 compression standard and adjustable compression quality
2. Compression/Playback Resolution: CIF
3. Support Audio and Video compression simultaneously
Network:
1. Use CloudSEE technology, easy operation, high connection rate and
good transmission effect
2. Use Client-end, IE and mobile phone for remote-viewing
3. Support remote-viewing, remote-recording, download remote-recording
files, remote-management and remote PTZ control
4. Automatically get network parameters, support PPPoE and remote connection
statistics
5. Support Web Service
Recording:
1. Support manual recording, schedule recording, motion detection recording
and alarm recording
2. Adjustable packaging time of recording files
3. Support remote-recording
4. Support audio recording
Playback:
1. Search recording file according to channel, time and recording type
2. Single channel or 4 channels playback
3. Multi-level fast or slow playing, Pause and Single Frame Play, 4 channels
synchronous operation
4. Show the status of playback
5. Support remote playback
6. Support audio playback
PTZ control:
1. Support exchanging PTZ control orders, Convenient for engineering works
2. Support pre-setting locations and software cruise of high dome camera
3. Support several main PTZ protocol
4. Operate the inter menu of camera
Backup:
1. Backup recording files into USB Device
2. Backup system log into USB Device
Alarm:
1. Support Motion Detection Alarm, up to 4 areas in each channel
2. Support Alarm Input Module Alarm, up to 32 channels alarm input
3. Alarm Output supports alarm recording, buzzer alarm, call pre-setting
locations of high dome camera, sending signal to client-end and IE, and
call Alarm Output module
4. Adjustable alarm duration
